Mitutoyo America
#511-788-20, 2-Point Inside Bore Gage for Short Length, 2-6″
This is a compact and lightweight bore gage due to the short length below the grip.
It offers you the following benefits:
-
Compact Reach: Features a short length below the grip, making it highly maneuverable and lightweight in confined spaces.
-
Heat Reduction: The grip is hollow-structured, reducing heat transfer from the operator’s hand by about 50% to maintain high measurement accuracy.
-
High Durability: Equipped with carbide-tipped contact points that ensure long-lasting wear resistance.
-
Plunger Stroke: Offers a longer plunger stroke without sacrificing measurement accuracy.
Technical Data:
-
Accuracy: 2μm / .00008”
-
Indication stability: 1μm / .00004”
-
Graduation: 0.01mm, 0.001mm, .0005” or .0001”
Specifications
| Range | 2 – 6″ |
| Graduation | 0.0005″ |
| No. Dial Indicator |
2922SB |
| Number of anvils | 11 (2″ sub anvil) |
| Number of spacers | 4 |
| Delivered | Including box, dial indicator, plastic cover for indicator |
| Stroke of contact point | 18 – 60 mm: 1.2 mm 50 – 160 mm: 1.6 mm |
| Repeatability | 0,5 µm |
| Digital/Analog | Analog |
| Inch-Metric | Metric |
